7280C (Arbitrary Repeat Type) Magnetic+Squeege Universal Type Rotary Screen Printing Machine
The 7280C series, based on the traditional rotary screen printing machine, enhances the adaptability of the equipment to different pattern sizes. The printed pattern repeat can be freely and steplably changed, with a maximum pattern repeat size of 1828mm. It enables rapid adjustment of pattern sizes, reducing the time for plate changing and adjustment. The equipment can be put into production more quickly, increasing output and meeting diverse production demands.
Technical parameters
1.Printing unit | ||||||||||||||
Model | 7280C (Arbitrary Type) | |||||||||||||
Nominal width(cm) | 180 | 200 | 220 | 240 | 260 | 280 | 300 | 320 | 340 | |||||
Effective printing width(cm) | 162 | 185 | 205 | 225 | 245 | 265 | 285 | 305 | 325 | |||||
Standard colors | 3/6/9/12 | |||||||||||||
Repeat size(mm) | 640~820~914~1018、1018~1450、1450~1828 | |||||||||||||
Printing varieties | Knitted fabric, woven fabric | |||||||||||||
Printing speed | 4~ 100m/min | |||||||||||||
Printing type | magnetic type + scraper type (any combination) | |||||||||||||
Alignment accuracy | ±0.1mm | |||||||||||||
Transmission mode | Guide belt drive: Physis servo motor | |||||||||||||
Printing unit: Independently driven by Europe servo motor | ||||||||||||||
Machine operation | Left/right hand (It is decided by the customer) | |||||||||||||
2.Feeding cloth unit | ||||||||||||||
Model | T2181 | T2280 | T2381 | T2480 | H2181 | H2280 | ||||||||
Type | woven fabric | woven /knitted fabric | woven /knitted fabric | knitted fabric | woven fabric | woven /knitted fabric | ||||||||
3.Dryer unit | ||||||||||||||
Model | S3013 | S3023 | S3033 | S3055 | ||||||||||
Dryer sections | 4/5 | 5 | 4/5 | 7/8 | ||||||||||
Applicable fabric | Thin fabric | Thin fabric | Thick fabric | Thick fabric | ||||||||||
Speed | 5~100m/min(50HZ) | |||||||||||||
Dryer temperature | 80℃~180℃ | |||||||||||||
heat source | Heat transfer oil/Steam/natural gas (standard: Heat transfer oil) | |||||||||||||
4.Power configuration | ||||||||||||||
Power supply | AC3-380V±10﹪,50Hz | |||||||||||||
Total power | 160 KW | |||||||||||||
Compressed air | 0.6~0.8MPa | |||||||||||||
Water source | 0.2~0.4MPa |
![]() | ![]() |
Advantages of the 7280C series
●The print pattern repeat can be freely and continuously changed, with a maximum pattern repeat of 1828mm
● The printing method can be a combination of magnetic rod type and scraper type
● Independent roller design for heavy fabrics
● Double-beam adjustable printing unit, easy to maintain and clean
● Pattern repeat is adjustable
Different pattern repeat lengths can be achieved on the same machine
It is possible to mix and produce patterns of different repetitive lengths
● Complex pattern superimposition
Support the superimposition printing of patterns with different pattern repeat lengths (such as large pattern repeat background + small pettern repeat embellishment)
● Enhance production flexibility
The variable pattern repeat model reduces the overall cost of small-batch orders by flexibly adjusting the pattern repeat
● Enhance the degree of automation
Automatically adjust the size of the pattern, reduce manual intervention, lower labor intensity, and enhance production efficiency and stability
● Reduce production costs
Flexibility avoids the cost of making screens specifically for different pattern sizes, reduces material waste and equipment idleness, and optimizes resource utilization
Applicable scenarios
● Small-batch and multi-variety production
Features: The order quantity is small, but there are a wide variety of patterns. Production tasks may need to be changed multiple times within a day.
The variable pattern repeat machine eliminates the downtime for gear replacement and searching for a specific circumference rotary screen, achieving "seamless switching" and significantly enhancing equipment utilization and production efficiency.
● Order-taking printing factory
Characteristics: The factory faces a wide range of customer groups, and the order demands are diverse, making it impossible to predict the Pattern repeat size of the next order.
Having a arbitrary repeat type rotary screen printing machine is equivalent to having a "full series" of pattern repeat printing machines. Factories can confidently accept orders from any source without worrying about being rejected due to technical limitations, which greatly enhances their market competitiveness.
● Personalized and customized production
Features: It meets the personalized customization needs of end consumers or brand customers, such as customizing unique pattern repeat curtains or clothing.
The ultimate embodiment of the variable spending function - "Minimum order one piece, arbitrary repeat." The machine perfectly adapts to every unique design.
Application field
● Clothing fabrics: Fast fashion brands, sportswear and casual wear
● Home textiles and furniture decoration: Bedding and curtains, sofas and decorative fabrics, carpets and walls
● Special textiles: Tourist souvenirs and silk scarves, automotive interior fabrics
